Product SKU: APC-T750TL-L24-SOL-DAG
Extra Heavy Duty 24V Motor with powerful and quiet operation. Robust all metal internal gears, sleek European design with a compact and neat appearance Easy to use manual override via the supplied keys in a emergency situation. The system can handle light and heavy gates up to 350kg maximum weight or up to 5m maximum length.
Top Limit Switches ensure precise setting of the open and closed positions along with a less strenuous life for the actuator.
|Gear Type||Metal Lead Screw, All metal gears|
Via override keys supplied
-10° - 50°
540mm (without limit switches)
The Proteous Logico 24 Control Unit provides the the latest enhanced technology and rich feature set of full programmability using the onboard intuitive LCD interface suitable for the novice user with simple setups all the way to 100% commercial sites with its advance features and its high duty cycle system.
There is no function or feature that this system cannot perform. See the full details below.
80% Duty Cycle (Can operate for up to 48 Minutes of every 60 minutes)
Full Feature MODERN Programmability by LCD Display (No DIP Switches or Dials)
Automatic learning of gate travel limits
Completly adjustable slowdown points
Configurable pedestrian operation travel amount which can be operated by remote, keypad, button, APP control (module available) and induction loop
Fast and Slow Speeds points are adjustable along with there power
Simple ONE PRESS full feature remote Ultra High Security Rolling Code learning system (and service free remote learning options)
Ultimate Auto close settings adjustable from 5 seconds to 20 Minutes
Party Mode System to keep gates opened when configured for use with the automatic close feature
Five underside cable entry with glands
All installation connections are low voltage (except in the case of high voltage driveway lights(low voltage can be used))
Energy Saving Mode (5mA Standby Current)
Standalone low voltage/high voltage driveway light control by remote (completely separate to the safety light)
Soft Start/Soft Stop (Ramping feature) with adjustable cut in points
Direct electric lock connection
Induction Loop Compatible for auto opening or as a safety device
Supports programmable timers
Adjustable Over current adjustments
Supports encoder motors and limit switch motors
Safety Sensor connection input configurable for open and/or closing
Supports Safety Edges
Automatic Courtesy Light Output (Blinking or Static illumination) with adjustable pre-operating courtesy times
Constant DC Accessories Output
Open/Stop/Close Inputs for Full Gate Operation and Pedestrian Gate Operation
Entry and Exit push button with isolation key switches (Wired and Wireless Options Available)
Keypads (Wired and Wireless Options Available)
Intercom system with dry contact output
Automatic switching timer
WiFi Control System (App Based Control)
GSM Control Systems (Mobile Call/SMS based Control)
|Optimum Operational Voltage||36V|
|Open Circuit Voltage||43.2V|
|20W Panel Dimensions||640 x 300 x 25mm|
|40W Upgrade Panel Dimensions||535 x 515 x 30mm|
|60W Upgrade Panel Dimensions||805 x 535 x 30mm|
The APC Uno is an articulate all in one design allowing for clean and secure housing the APC Sun Power Solar Regulator and multiple batteries.
Supplied with the automation kit the 24V 9aH battery system will allow for continued use of the gate system wether in day or night. The system can operate for up to one week of regular residential use without any charge from the solar panel (winter months/wet season) and will automatically recharge from sun light. When the system batteries are fully charged it will continue to float charge to keep the batteries topped up ready for use. In a case of extended use requirments or higher duty there are upgrade options to 17aH and 33aH battery systems.
|Power Input||24V (Uno Solar System)|
|Rectification||In Box Rectifier|
|Motor Output Voltage||24v DC|
|Max Operating Power||250 Watts (Accesories + Running Motors)|
|Max. Accesories Load||7W|
|Control Board Duty Cycle||80%|
|Working temperature||-20° - 50°|
|RF||APC Rolling code 433.92mhz|
|Auxiliary Inputs||0V Momentary Pulse|
|Accessories Voltage||24V DC|
|Operator Inbuilt Safety||Over current + Encoder Sensitivity|
The APC Connect 4 will allow all programmed users to ring the device from anywhere, at anytime with the ability to toggle the connected device to operate. If desired the unit can also be set to a public mode so that any telephone number to call in can toggle the operation.
The administrator/installer can easily adjust the method of operation and toggle from the systems features by sending simple SMS commands from there mobile phone.
An active Sim Card with good to excellent mobile coverage in the are the Connect 4 will be installed. The Sim Card cannot be a data Sim and must have an active telephone number.
Voicemail feature of the Sim Card must be disabled, The service provider (Telstra, Optus, Vodafone, Aldi etc.) can do this for you.
The push button can be used for over 50 metres in operating distance.
The APC booster antenna is suitable for gate automation systems, garage doors, receivers and any other devices using the 433mhz or 433.92mhz radio frequency band.
As a general rule of thumb on a properly function system you can expect to see results of doubling the range of the transmitter.
The antenna can also help in resolving issues where the transmitter range is decreased due to installation methods such a receiver being behind a metal fence, brick pillar , metal box and numerous other range decreasing factors
