Single Channel 24V Induction Loop Detector

Product SKU: APC-LD1-24VACDC

  • In Stock

Get More Info.. Get More Info..

Kit Price:

$84.00

  • Or in 4 payment of $21.00 with afterpay info

Add-On Items (Discounted when purchased along with this Kit)

Product Information



Product Code: APC-LD1-24VAC/DC

Single Channel Loop Detector



Usage of Loop Detector:
The APC-LD1 is a loop detector sensor module that is used wherever vehicles need to be detected. The loop detector can be connected to any of the following types of systems that allow the use of a loop detector:
- Driveway Gate Mechanisms
- Operating Barrier Mechanisms
- Traffic Light Systems in car parks

How it Works:
The loop detector is housed in the controller box/enclosure of the connected mechanism and is used to communicate with the underground inductive loop wire when a vehicle is detected which then sends a signal to the connected system to open the mechanism, close the mechanism or prevent the system from closing.




Specifications


Voltage: 24V AC/DC
Voltage Tollerance AC: +10% / -15%
Voltage Tollerance DC: +/- 15%
Power Consumption: 4.5VA
Output Relays: 240V/5A
Frequency Range: 20 kHz to 170 kHz
Reaction Time: 10ms
Signal Holding Time: Unlimited, Limited when loop is permanently covered
Sensitivity: Adjustable in 4 increments
Wiring: Recommend 100μH to 300μH
Operating Temperature: -20°C to +65°C
Storage Temperature: -40°C to +85°C


Typical Loop Layout Diagram 1




Typical Loop Layout Diagram 2




Typical Loop Wiring Measurements



Approximate Loop Sizes

Driveway Width
Loop Size
3m - 4.5m 1.8m x 1.2m
4.8m - 5.4m 2.4m x 1.2m
5.8m - 6.7m 3m x 1.2m
7m - 7.9m 4.3 x 1.2m


Loop Wiring Diagram
