Product SKU: BG30-HS-800-DC-WF

Lightning Speed (50cm/s), Brushless 36V, 800kg, Sliding Gate Opener Wi-Fi Access Control Kit|100% Italian Made by Roger Technology BG30/804/HS Rolling Gate Automation System. Ultra-High ⚡ Speed 100% Duty Cycle 800kg Capacity Brushless 36V Sliding Gate Motor With Magnetic Limits, Remote Controls, Reflective Safety Sensor and APC MONDO Wi-Fi Keypad Smart Access Control

Upload Images (Max. 5 images can be uploaded)

Upload
no file chosen

  • On Sale

Lightning Speed (50cm/s), Brushless 36V, 800kg, Sliding Gate Opener Wi-Fi Access Control Kit|100% Italian Made by Roger Technology BG30/804/HS Rolling Gate Automation System. Ultra-High ⚡ Speed 100% Duty Cycle 800kg Capacity Brushless 36V Sliding Gate Motor With Magnetic Limits, Remote Controls, Reflective Safety Sensor and APC MONDO Wi-Fi Keypad Smart Access Control

Product SKU: BG30-HS-800-DC-WF

  • In Stock

  • New
Get More Info..
Free Shipping Free Shipping

Kit Price:

$1,999.00 $2,445.00 APC Automotion Plus Sale

  • Or in 4 payment of $499.75 with afterpay info
  • Lightning Speed (50cm/s), Brushless 36V, 800kg, Gate Opener, 100% Italian Made by Roger Technology Sliding Gate Motor

  • Kit Includes

    01 Lightning Speed Brushless 800kg 36V Sliding Gate Opener Motor|100% Italian-Made Roger Technology BG30/800/HS Ultra High-Speed (50cm/s) Brushless Electromechanical Roller Gate Motor (QTY: 1)
    02 Roger Technology Two-Button Remote Control (QTY: 2)
    03 APC Mondo Wi-Fi Keypad with APP Control and Swipe Tag Reader (QTY: 1)
    04 EM Swipe Tag (QTY: 2)
    05 5m 4 Core Non Shielded Cable (QTY: 1)
    06 Gear Rack Nylon Coated With Steel Core, Strong and Quiet - (1m Pack - 2 x 50 CM) Made in Italy by Stagnoli (QTY: 4)
    07 Concrete In Fixing Plate with Stay Bolts and Screws for Roger Technology Sliding Gate Motor M30 series. (QTY: 1)
    08 Roger Technology FIVE YEAR Parts Warranty on Stator and Rotor of the Brushless Digital Motor and TWO YEAR Warranty on All Other Parts Including Electronics (Excluding consumables - remotes, batteries etc) (QTY: 1)
    09 FREE APC Retro Reflective Safety Sensor - for Gate Opening System Safety Retro Reflective Gate Sensor (QTY: 1)
  • Customise Kit
  • Add-On Items
  • Product Information

Customise your Kit

Add-On Items (Discounted when purchased along with this Kit)

Product Information

100% Italian Made BG30/804/HS BRUSHLESS Sliding Gate Motor, Lightning Speed (50 cm/s) Sliding Gate Opener.

ROGER TECHNOLOGY HIGH-SPEED

 Animal instinct, digital lightning speed

A FASTER WAY TO WATCH YOUR GATE MOVE!

One of the Best Sliding Gate Motor now on sale in Automotion Plus Melbourne/Australia

How to Choose the Best Sliding Gate Opener (Australia)? | APC Gate Automation (Melbourne/Australia)

The best-sliding gate motors in Australia are often determined by factors such as reliability, durability, speed, access control, and customization options. Some top Automotion Plus Sliding Gate Opener models to consider include:

Roger Technology Brushless BG30 series sliding gate motor is strong, durable, and high-quality, suitable for residential and commercial sliding gates. It uses 36V brushless motor digital technology.

One of the best-sliding gate motors, the BG30/804/HS lightning speed brushless internal motor, allows for an 800kg capacity, making it the ideal candidate for the majority of gate installations for domestic/industrial driveway gates.

If you are looking for the best sliding gate motors in Australia, several models should be considered. Some popular options include the Italian-made BG30/HS Sliding Gate Motor 36V DC series and the BM30/HS Brushless Sliding Gate Motor 24V DC series. These motors are known for their reliability, smooth operation, ultra-high speed, intensive use, advanced access control, safety features such as safety sensors, WiFi smartphone app integration, and much more. When choosing the best sliding gate motor, it's important to consider factors such as gate size, weight, power options (Grid Power 240V, External Transformer Low Voltage 24V and Solar Off-Grid) and also speed, intensive use and warranty.

"Roger Technology FIVE YEARS Parts Warranty on the Stator and Rotor of the Brushless Digital Motor and TWO YEARS Warranty on All Other Parts, Including Electronics (*excluding consumables - remotes)"

You can get a free consultation from our help-desk professional to ensure the motor is the best compatible with your specific gate setup and requirements.

Please contact us to find the best sliding gate opener for your needs with the help of our experienced technicians.

Digital Lightning Speed Sliding Gate Motor Made in Italy by Roger Technology | The Best Sliding Gate Motors in Australia

With the new high-speed line, digital Lightning Speed, it is possible to open and close your gate at very high speed, with maximum elegance and more than doubling the decrease in waiting times of other operators for gate automation.

This is the ideal solution for all installations requiring speedy manoeuvre times, intensive use, maximum movement elegance, and total safety during the movement and obstacle detection phases.

Faster speeds and shorter waiting times!
The new Lightning Speed lines let you quickly, powerfully and reliably open a gate. They are 100% faster compared to the traditional speeds for motors with BRUSHLESS 36V DC Moror technology.


Dynamic accelerations and decelerations!
Thanks to the new 24V or 36V digital controllers, it has become fast and straightforward to set different types of accelerations and decelerations during your gate's opening and closing phases. And always guaranteeing maximum elegance and safety.

Digital obstacle detection!
The ultra-powerful Native Encoder onboard the digital technology and the brand new motor power control in sensor technology make it possible to detect any obstacle with maximum safety, setting the speed, motor torque, sensitivity and operator reaction time during the detection phase for possible obstacles.

Total safety from the point you want!
To guarantee maximum safety and maintain high-speed performance, the new digital controller offers the possibility of configuring gate opening and closing from where you want to start deceleration and setting the type of deceleration, its speed and the relative sensitivity you want.



Roger Technology Brushless BG30/804/HS Sliding Gate Motor

BRUSHLESS 36V  LIGHTNING SPEED Sliding Gate Automation Motor | with magnetic limit switch





At a glance | Brushless 36V Lightning Speed Automatic Sliding Gate Opener / Roller Gate Automation System

The Roger Technology BG30/804/HS Brushless complete kit includes the roller sliding gate motor, control panel, and receiver.

The BG30/804/HS motor is a low voltage, super intensive use with native encoder onboard, irreversible ideal for sliding gates up to 800Kg with built-in digital controller B70 series, magnetic limit switch.

Includes:

- BG30/804/HS Electromechanical Brushless Sliding Gate Motor
- Built-in B70 36v Digital Control Panel
- Plug-in H93/RX20/I Receiver
- Magnetic Limit Switch

See the full details below.



Roller Gate Automation System Features

  • Ideal: For sliding gates up to max. 800 kg.
  • Safe: The encoder management allows precise and safe control of slowdown when opening and closing.
  • Practical: Automatic programming via the learning function of the control unit.
  • Quick: Ease of installation and start-up due to its simple functions and its height and depth adjustments.
  • Strong: Features a sturdy aluminium base treated with anti-corrosive paint and a reliable Roger Brushless motor mounted in dedicated housings and bearings.
  • Equipped with a release lever and an easy-to-operate lock.
  • Convenient: Battery backup available.



Capacity

  • 100% Duty Cycle (opening/closing - 24 hours, no stop)
    Digital brushless motor based on a permanent magnetic field that uses neodymium iron-boron magnets inside the rotor.
  • Multifunction digital display
    4-quadrant digital display with six function keys allow you to go through the various parameters, change their values, check error messages and input statuses and perform all the self-learning phases.
  • 800KG Capacity
  • LIGHTNING Speed (50 cm/s) | Roller Gate Automation System)





BRUSHLESS MOTOR TECHNOLOGY

A digital brushless motor with a permanent magnetic field and digital electronics for the complete management of the automation system control. Designed for super intensive use with the added benefit of super low energy consumption.



DIGITAL BRUSHLESS MOTOR

Innovative, revolutionary Brushless digital motor with permanent magnetic field, 24V/36V energy sinusoidal with a native encoder that permits highly intensive use of the automation with extremely reduced consumption whilst at the same time fully guaranteeing all its safety and management functions.

NEW GENERATION OF ELECTRONICS

The new control unit with onboard Brushless digital controller (24V/36V DC). Without traditional relays and thanks to its revolutionary MOSFET quadrant system and its control technology entirely based on a DSP microcontroller, it represents a new generation of electronic cards created to safely handle every type of automation movement.

ENGINEERING PASSION

All the mechanical components and gears are manufactured in steel, cast iron and bronze. The automation system casings are made from titanium-reinforced die-cast aluminium. All the gears are inspected and assembled on high-quality bearings and inserted on precise seats machined to provide absolute precision between the axes.



Special Features of Brushless 36V Lightning Speed Automatic Sliding Gate Opener

WHY BRUSHLESS...?

Digital, smart, powerful, elegant, robust and all-Italian.

A technology that offers maximum performance but consumes less power than other motors. The revolutionary digital motor with 12 unique features.

Powerful Digital Brushless Motor

A very powerful sliding gate motor with substantial torque. The motor is compact and neat due to the special concentrated coil windings, it is powered by an energy sinusoidal system.

Digital & Vectorial Automation Controller

The BRUSHLESS digital controller, which operates at low voltage DC, allows 100% control of the automation system in digital mode. Due to its operation entirely based on a DSP microcontroller, the travel and your automation system's movements can be programmed and customised easily, precisely and elegantly.

The Digital Silence Of The Motor

One great impact is the silence or the near absence of noise generated by the BRUSHLESS motor during all its movements.

 Motor For Super-Intensive Use

 The brushless gate motor remains permanently cold even after many days of super-intensive use.

Speed, Acceleration & Deceleration With Extreme Elegance

The automation system with brushless digital technology creates perfect and elegant movements. With a constant force and torque at every point and the option of varying the speed of deceleration and acceleration, the system can be managed with maximum safety.

Extremely Low Energy Consumption

A motor that can operate at low voltage in super-intensive use and operate in environments with highly demanding weather conditions while maintaining very low energy consumption and absorption levels.

Impact, Obstacle Detection & Reversal In Total Safety

Thanks to digital technology, we are able to detect an obstacle and reverse the motor instantly by simply specifying the torque of the motor, the sensitivity, the time and the travel of the reversal, all in full compliance with safety requirements.

Onboard Native Digital Encoder

The BRUSHLESS motor has a highly advanced native digital encoder that controls the management of automation systems in a safe, precise and extremely elegant manner.

No Problem In The Event Of Power Failure

With the help of internal or external batteries and the associated battery charging card, your automation system continues to operate considerably even during prolonged power cuts, ensuring many more operations than traditional technologies.

Motor At Ambient Temperature

The brushless motor was created with the main goal of being a motor for super intensive use and with a 99% efficiency. Regardless of how many operations the engine performs in a day, it always remains cold or, at the most, reaches the outside ambient temperature.

Simple Installation With A Single 3-Wire Cable

And the BRUSHLESS motor can be installed by simply connecting it using a single 3-wire cable! What could be easier? This will provide fully digital management of your automation system thanks to sensorless or sensored technology, depending on the type of automation system.

Advanced Precision Engineering To Obtain Optimal Motor Performance

We have created a mechanism that gives you the opportunity to get the maximum performance out of the motor. A product that combines the quality of the internal production processes, mechanical processing, and high-quality ferrous and non-ferrous materials.



Control Board Overview



Accessories Compatibility and Controlling Options | Roller/Sliding Gate Automation

  • Constant DC Accessories Output
  • Automatic Sliding Gate Open/Stop/Close Inputs for Full Gate Operation and Pedestrian Gate Operation
  • Remote controls
  • Induction Loops
  • Weekly Timers
  • Entry and Exit push button with isolation key switches (Wired and Wireless Options Available)
  • Keypads (Wired and Wireless Options Available)
  • Exit/entry sensors
  • Intercom system with dry contact output
  • Automatic switching timer
  • WiFi Control System (APP-Based Control)
  • GSM Control Systems (Mobile Call/SMS-based Control)



Remote Control Features

E80/TX52R/2

Fix code transmitter 433,92 Mhz. 2 channels, with radio for copy.

Technical features

Standard power: 3V DC
Absorption: 12mA
Operating temperature: -10+55 °C
The number of channels: 2
Codification: Fix code
Modulation: AM/ASK
Carried frequency: 433.92MHz
The number of combinations: 65536
Radio for a copy: Yes
The maximum distance in the open field: 150m
Battery: Mod "CR2032" 3V
Maximum dimension product in mm
(L x W x H):
38 x 68 x 11
Product weight packed (Kg): 0,03






Italian-Made Roger Technology BH30/804/HS BRUSHLESS 36V LIGHTNING-SPEED Sliding Gate Electric Motor
| DIMENSIONS |



Italian-Made Roger Technology BH30/HS BRUSHLESS 36V LIGHTNING-SPEED Roller Gate Electric Motor
| SPECIFICATIONS |

Max gate weight:    800 kg
Power line supply:    230V AC - 50Hz
Motor power supply:    36V
Power rating:    490W
Frequency of use:    Intensive use
Thrust:    50 - 650N
Operating temperature:    -20+55°C
Protection level:    IP44
Reductor Type:    Irreversible
Manoeuvre speed:    30 m/min (0.5 m/s)
Limit switch:    Magnetic
Onboard control unit:    B70/1DCHP
Encoder:    Digital native encoder + magnetic digital SENSORED, 4096 PPR
Batteries recovery:    Optional 2 external battery 12V 4,5AH
Type exit gear:    Z20/mod 4
Operating cycles per day (opening/closing - 24 hours no stop):    800
Maximum dimension product in mm (L x W x H):    350 x 220 x 380



Standard Accessories

KT215

Fixing plate with stay bolts and screws G30 series.

MC775

Kit magnetic limit switch for the control units H70/103AC, H70/104AC, B70/1DC, and B70/1DCHP.



Optional Add-On Raised Fixing Plate

KT222

Raised fixing plate for G30 series (+3.5 cm).







(2 x 50 CM) Nylon Gear Racks 1 Meter Pack | Made in Italy by Stagnoli

Interlocking Gear Racks Made in Italy by Stagnoli

The Keyed Interlocking Modular Nylon Gear Rack is Compatible with All Sliding Gate Automation

Stagnoli, Italy invented the nylon racks and has been manufacturing nylon racks since 1981. The advantage of nylon racks is no lubrication, rust-free and silent. Furthermore, with the nylon rack, there is no need to carry out any welding, which is instead required for iron racks and which involves more machining in the assembly process. GR50 is a quality product and is completely Made in Italy.







Dimensions of Modular Nylon Gear Racks | Sliding Gate Hardware

This gear rack nylon coated with steel core, strong and quiet, is compatible with all sliding gate automation, and is easy DIY install.


Modular gear racks kit includes;

A box with 2 nylon gear racks measuring 50 cm, 4 self-tapping and self-piercing screws, and 4 washers in galvanized steel. (Made in Italy by Stagnoli)







APC Mondo Wired Keypad with APP via Wi-Fi



The APC Mondo Wi-Fi Keypad can be used as a simple keypad access control device or alternatively as an advanced unit. Its special features allow the system to be operated by Pin Code, Swipe Tag and even remotley by APP whether on-site or off-site (anywhere in the world).

Supplied with a 10 meter cable roll it is wired back to the main control board of the system. Its also supplied with two swipe tags for PIN FREE access.


Key Feature Set:

  • Full operational control by Tuya APP
  • Resin Filled for best weatherproofing
  • Low Power Consumption
  • Backlit Touch Keys
  • Up to 2000 Users
  • Pin Code, Swipe Tag or DUAL AUTHENTICATION Swipe Tag then Pin Code
  • Adjustable Relay Time from 0-99s or Latching ON/OFF
  • Doorbell Contacts to connect to your doorbell system



APC-RR-11 Retro Reflective Sensor



The retro-reflective Safety sensor set is used to prevent the closing cycle occurring during the case of the sensor path being interrupted by vehicles, trailers or any other obstacles.

If the gate begins to close and the sensor path is interrupted then the gate will stop and return to the open position.

The sensor ( which is the transmitter and receiver) is wired back to the control box of the gate system using the pre-connected cable. There is no requirement for wiring across the driveway using this type of sensor.

  • Up to 11 Metres Infrared beam operating distance

  • Only powers on when the command is given to close the gates

  • Alignment & Misalignment led to assist in the installation process

  • Resin filled for the ultimate weatherproofing





Your Customised Kit Includes:

No Changes.
        • Kit Quantity:
          • 1
        • Your (Kit and Add-On) Price:

          $1,999.00
